Descripción
TECHNICAL DATA
GENERAL
Input voltage
100 – 240 VAC
Input frequency
50 / 60 Hz
Input current
3.9 A
Input connector
US (Type A)
Output voltage
54 VDC
Output current
4.62 A
Output connector
2-pin, with cord end terminals
Weight
910 g
ADDITIONAL
Input voltage range
90 – 264 VAC
Input frequency range
47 – 63 Hz
Maximum input inrush current
60 A
Output voltage maximum deviation
51.3 – 56.7 VDC
Short circuit protection
✓
HIPOT (dielectric withstand test)
Primary to Secondary: 1500 VAC
Certification
Safety: IEC62368-1 (CB Scheme), UL 62368-1:2014, CAN/CSA-C22.2 No. 62368-1-14
EMC: FCC Part 15:2019 / ANSI C63.4:2014
Características
- Voltaje de entrada 100-240 VAC, adaptable internacionalmente
- Corriente de entrada máxima de 3.9 A
- Salida de 54 VDC para equipos profesionales
- Protección contra cortocircuito incorporada
- Certificaciones de seguridad IEC, UL y CAN/CSA
